HED1107E Harsh Environment Display
The HED1107E display is a 7-inch rugged display, using a 24-bit color LCD screen with a resolution of 1024×600 and a brightness of up to 650 cd/m², providing a clear display. It is equipped with 9 buttons, 1 knob, and touch functionality for convenient operation. It has a wide operating temperature range (-30℃ to 75℃) and an IP65 protection rating, making it suitable for extreme environments. It is equipped with a RISC-V 600MHz processor for stable performance and supports two AHD 1080P cameras and 10 input/output channels to meet various application needs. It has large storage space, supports voice alarms, is compatible with Deutsch DTM interfaces and 4-pin aviation connectors for flexible installation, meets electromagnetic compatibility standards, has a built-in real-time clock, and supports wide voltage input (8-32VDC). It is an ideal choice for industrial automation and monitoring fields. Its features include high-definition display, convenient operation, strong environmental adaptability, high-performance processor, large storage capacity, abundant input/output channels, camera support, flexible installation and connection, good electromagnetic compatibility, real-time clock, and wide voltage input, making it an excellent product in industrial automation and monitoring fields.
Advantages:
1. High-definition display and high brightness:
Using a 7-inch 24-bit color LCD screen with a resolution of 1024×600, a large display area, high contrast and brightness (typical value 650 cd/m²), providing a clear and vivid visual effect.
2. Convenient operation:
Equipped with 9 buttons (with backlight) and 1 knob for flexible and convenient operation. Supports touch operation to enhance user experience.
3. Strong environmental adaptability:
Wide operating temperature range (-30℃ to 75℃), even wider storage temperature range (-40℃ to 85℃), suitable for various extreme environments. The protection level reaches IP65, effectively preventing dust and water, and improving product durability.
4. High-performance processor:
Using a RISC-V 600MHz processor, providing stable computing performance and fast response speed.
5. Large storage capacity and voice alarm:
RAM 128MB, Flash 32MB, meeting data storage and processing needs. Supports voice alarm output, storage capacity up to 2GByte, can directly drive a speaker.
Features:
1. Abundant input/output channels:
Supports up to 10 input/output channels (9 inputs/4 outputs), including digital input, analog voltage input, analog resistance input, etc., to meet the needs of different application scenarios.
2. Camera support:
Supports two AHD 1080P cameras, providing high-definition video monitoring capabilities.
3. Flexible installation and connection:
Compact size (228x146x50mm), supports embedded installation or RAM bracket installation. Compatible with Deutsch DTM sockets and sheaths, as well as 4-pin aviation connectors, for easy integration and maintenance.
4. Good electromagnetic compatibility:
Complies with GB/T 17626 series electromagnetic compatibility testing standards and specifications, test level 4, ensuring stable operation of the product in complex electromagnetic environments.
5. Real-time clock and wide voltage input:
Built-in real-time clock for convenient time management and data recording. Supports wide voltage input (8-32VDC) to adapt to different voltage environments.
